Emulex LightPulse LPE16004-M6 Quad-Port 16Gb Gen 5 Fibre Channel Host Bus Adapter


$2,472.50




  • New Factory Sealed
  • 90 day warranty
  • Model Number: LPE16004-M6
  • Port Configuration: Quad-Port 16Gb Fibre Channel (16GFC)
  • Interface: PCI Express 3.0 x8
  • Connector Type: LC SFP+ Short Wave Optical
  • Data Transfer Rate: Up to 16 Gbps per port
  • Form Factor: Full-height, half-length PCIe card (111.15 mm x 167.64 mm)
  • Maximum IOPS: Up to 2.4 million I/O operations per second
  • Supported Fibre Channel Protocols: Class 2 and 3
  • Backward Compatibility: Supports 16GFC, 8GFC, and 4GFC devices
  • Advanced Features:
    • ExpressLane™ for Quality of Service (QoS) prioritization
    • ClearLink diagnostic support for Brocade switches
    • T10 Protection Information (T10-PI) for end-to-end data integrity
  • Power Requirements: +3.3V, +12V
  • Operating Temperature: 0°C to 55°C (32°F to 131°F)
  • Management Tools: Emulex HBA Manager for centralized management

This high-performance adapter is ideal for enterprise data centers requiring robust and scalable Fibre Channel connectivity, especially in environments with slot constraints. Its advanced features ensure efficient data handling and reliable performance for mission-critical applications.
